2.5 Control terminal specification
T/M
Terminal Description
Wire size[mm
2
]
Screw
size
Torque
[Nm]
Specification
single
wire
Stranded
P1~P8
Multi-function input T/M 1-8
1.0
1.5
M2.6
0.4
CM
Common Terminal
1.0
1.5
M2.6
0.4
VR
Power supply for external
potentiometer
1.0
1.5
M2.6
0.4
Output voltage: 12V
Max output current:
100mA
Potentiometer:1 ~ 5kohm
V1
Input terminal for Voltage
operation
1.0
1.5
M2.6
0.4
Max input voltage:
-10V ~ +10V input
I
Input terminal for Current
operation
1.0
1.5
M2.6
0.4
0 ~ 20mA input
Internal resistor: 250
ohm
AM
Multi-function analog output
terminal
1.0
1.5
M2.6
0.4
Max output voltage: 11[V]
Max output current:
10mA
MO
Multi-function terminal for
open collector
1.0
1.5
M2.6
0.4
Below DC 26V,100mA
MG
Ground terminal for
external power supply
1.0
1.5
M2.6
0.4
24
24V External Power Supply
1.0
1.5
M2.6
0.4
Max output current:
100mA
3A
Multi-function relay output A
contact
1.0
1.5
M2.6
0.4
Below AC 250V, 1A
3B
Multi-function relay output
B contact
1.0
1.5
M2.6
0.4
Below DC 30V, 1A
3C
Common for Multi-function
relays
1.0
1.5
M2.6
0.4
Note 1) Tie the control wires more than 15cm away from the control terminals. Otherwise, it interferes
front cover reinstallation.
Note 2) Use Copper wires rated 600V, 75 ℃ and higher.
Note 3) Use the recommended tightening torque when securing terminal screws.
Note
When you use external power supply (24V) for multi-function input terminal (P1~P8), terminals will
be active above 12V level. Take caution not to drop the voltage below 12V.
