Keypad/ Terminal/ Communication option/ Remote keypad
selectable
Analog: 0 ~ 10[V], -10 ~ 10[V], 0 ~ 20[mA]
Digital: Keypad
Multi-function terminal
P1 ~ P8
NPN / PNP selectable (See page 2-13)
FWD/REV RUN, Emergency stop, Fault reset,
Jog operation, Multi-step Frequency-High, Mid, Low, Multi-step
Accel/Decel-High, Mid, Low, DC braking at stop, 2
nd
motor
select, Frequency UP/Down, 3-wire operation, External trip A, B,
PID-Inverter (v/f) operation bypass, Option-inverter (v/f)
operation bypass, 2
nd
Source, Analog Hold, Accel/Decel stop,
Up/Down Save Freq, Jog FX/RX
Fault output and
inverter status output
(N.O., N.C.) Less than AC250V 1A,
Less than DC 30V 1A
0 ~ 10 Vdc (less than10mA): Output Freq, Output Current,
Output Voltage, DC link selectable
Over Voltage, Under Voltage, Over Current, Over Current 2, Ground Fault current
detection, Inverter Overheat, Motor Overheat, Output Phase Open, Overload
Protection, Communication Error, Loss of Speed Command, Hardware Fault, Fan trip,
Brake error.
Stall prevention, overload
Below 15 msec: Continuous operation (should be within rated input voltage, rated
output power.)
Above 15 msec: Auto restart enable
1) Single Phase products: Continuous operation (should be within rated input voltage, rated output
power)
Environment
IP 20, UL TYPE1 (Ambient Temperature 40 C)
2)
Below 90% RH (no condensation)
Below 1,000m, 5.9m/sec
2
(0.6G)
Protected from corrosive gas, combustible gas, oil mist or dust
2) UL TYPE1 with top cover and conduit box installed.
