LSIS sv-ig5a User Manual

4-9
 Navigating codes in a group
When moving from F 1 to F 15 in Function group 1
1
-. In F 1, continue pressing the Up ()
key until F15 is displayed.
2
-. Moving to F15 has been complete.
 The same applies to Function group 2 and I/O group.
Note: Some codes will be skipped in the middle of increment ()/decrement () for code
change. That is because it is programmed that some codes are intentionally left blank for
future use or the codes user does not use are invisible.
Refer to the Ch.5 for more specific contents
For example, when F24 [High/low frequency limit select] is set to “O (No) ”, F25 [High
frequency limit] and F26 [Low frequency limit] are not displayed during code change. But
When F24 is set to “1(Yes)”, F25 and F26 will appear on the display.
