LSIS sv-ig5a User Manual

5-12
 Function group 2
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during run
Page
H27
A31B
[Auto Restart
time]
0~60 [sec]
This parameter sets the time
between restart tries.
1.0
O
8-20
H30
A31E
[Motor type
select]
0.2~ 22.0
0.2
0.2kW
7.5
1)
X
8-16
~
~
22.0
22.0kW
H31
A31F
[Number of
motor poles]
2 ~ 12
This setting is displayed via rPM
in drive group.
4
X
H32
A320
[Rated slip
frequency]
0 ~ 10
[Hz]








120
Prpm
ff
rs
Where,
s
f
= Rated slip frequency
r
f
= Rated frequency
rpm
= Motor nameplate
RPM
P
= Number of Motor
poles
2.33
2)
X
H33
A321
[Motor rated
current]
0.5~150
[A]
Enter motor rated current on the
nameplate.
26.3
X
H34
A322
[No Load
Motor Current]
0.1~ 100 [A]
Enter the current value detected
when the motor is rotating in rated
rpm after the load connected to
the motor shaft is removed.
Enter the 50% of the rated current
value when it is difficult to
measure H34 – [No Load Motor
Current].
11
X
H36
A324
[Motor
efficiency]
50~100
[%]
Enter the motor efficiency (see
motor nameplate).
87
X
H37
A325
[Load inertia
rate]
0 ~ 2
Select one of the following
according to motor inertia.
0
X
8-1
0
Less than 10 times
1
About 10 times
2
More than 10 times
1)
: H30 is preset based on inverter rating.
2)
: H32 ~ H36 factory default values are set based on OTIS-LG motor.
