 Function group 2
LED
display
Address
for
commu-
nication
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
H55
A337
[PID output
frequency
high limit]
0.1 ~
400
[Hz]
This parameter limits the amount of the
output frequency through the PID control.
The value is settable within the range of
F21 – [Max frequency] and F23 – [Start
frequency].
60.00
O
8-10
H56
A338
[PID output
frequency
low limit]
0.1 ~
400
[Hz]
0.50
O
H57
A339
[PID
standard
value select]
0~4
Selects PID standard value.
Standard value is indicated in “rEF” of
Drive group.
0
X
8-10
0
Loader digital setting 1
1
Loader digital setting 2
2
V1 terminal setting 2: 0~10V
3
I terminal setting: 0~20mA
4
Setting as a RS-485
communication
H58
A33A
PID control
unit select
0~1
Selects a unit of the standard value or
feedback amount.
0
X
0
Frequency[Hz]
1
Percentage[%]
H60
A33C
[Self-
diagnostic
select]
0 ~ 3
0
Self-diagnostic disabled
0
X
8-22
1
IGBT fault/Ground fault
2
Output phase short & open/
Ground fault
3
Ground fault (This setting is
unable when more than 11kW)
H61
1)
A33D
[Sleep delay
time]
0~2000
[s]
Sets a sleep delay time in PID drive.
60.0
X
8-13
H62
A33E
[Sleep
frequency]
0~400
[Hz]
Sets a sleep frequency when executing a
sleep function in PID control drive.
You can‟t set more than Max.
frequency(F21)
0.00
O
H63
A33F
[Wake up
level]
0~100
[%]
Sets a wake up level in PID control drive.
35.0
O
H64
A340
[KEB drive
select]
0~1
Sets KEB drive.
0
X
8-28
H65
A341
[KEB action
start level]
110~140
[%]
Sets KEB action start level according to
level.
125.0
X
H66
A342
[KEB action
stop level]
110~145
[%]
Sets KEB action stop level according to
level.
130.0
X
1):
Set H49 as a 1
2):
it is indicated when setting H64(KEB drive select) as a 1
(KEB does not operate when cut power after loading ting input (about 10%).
