Page #66 background imageLoading...
Page #66 background image
5-18
Input/output group
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
I 0
A400
[Jump code]
0 ~ 87
Sets the code number to jump.
1
O
4-5
I 2
A402
[NV input
Min voltage]
0 ~ -10
[V]
Sets the minimum voltage of the NV (-
10V~0V) input.
0.00
O
7-2
I 3
A403
[Frequency
correspondi
ng to I 2]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum voltage of the NV
input.
0.00
O
I 4
A404
[NV input
Max
voltage]
0 ~ -10
[V]
Sets the maximum voltage of the NV
input.
10.0
O
I 5
A405
[Frequency
correspondi
ng to I 4]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum voltage of the
NV input.
60.00
O
I 6
A406
[Filter time
constant for
V1 input]
0 ~ 9999
Adjusts the responsiveness of V1 input
(0 ~ +10V).
10
O
7-2
I 7
A407
[V1 input
Min voltage]
0 ~ 10
[V]
Sets the minimum voltage of the V1
input.
0
O
I 8
A408
[Frequency
correspondi
ng to I 7]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum voltage of the V1
input.
0.00
O
I 9
A409
[V1 input
Max
voltage]
0 ~ 10
[V]
Sets the maximum voltage of the V1
input.
10
O
I10
A40A
[Frequency
correspondi
ng to I 9]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum voltage of the
V1 input.
60.00
O
I11
A40B
[Filter time
constant for
I input]
0 ~ 9999
Sets the input section‟s internal filter
constant for I input.
10
O
7-4
I12
A40C
[I input Min
current]
0 ~ 20
[mA]
Sets the minimum current of I input.
4.00
O
I13
A40D
[Frequency
correspondi
ng to I 12]
0 ~ 400
[Hz]
Sets the inverter output minimum
frequency at minimum current of I input.
0.00
O
I14
A40E
[I input Max
current]
0 ~ 20
[mA]
Sets the Maximum current of I input.
20.00
O
I15
A40F
[Frequency
correspondi
ng to I 14]
0 ~ 400
[Hz]
Sets the inverter output maximum
frequency at maximum current of I
input.
60.00
O
7-4
I16
A410
[Criteria for
Analog Input
Signal loss]
0 ~ 2
0: Disabled
1: activated below half of set value.
2: activated below set value.
0
O
10-7
I17
A411
[Multi-
function
input
terminal P1
define]
0 ~ 27
0
Forward run command
0
O
7-8
1
Reverse run command
I18
A412
[Multi-
function
input
terminal P2
define]
2
Emergency Stop Trip
1
O
-
3
Reset when a fault occurs {RST}
-
