169441 11 Revision D
ϭϬϰϬϭϰϵ
A
A
B
B
Figure 1.18: Slow Speed Transport Tow-Bar
A - MD #193113 B - MD #129261
NOTE:
Decal MD #129261 has two different appearances in this illustration as the decal has changed over the years. The version
shown attached to the tow-bar is an older version; the version at the bottom of the illustration is the current version.
ϭϬϰϬϭϱϭ
A
A
Figure 1.19: Vertical Knife
A - MD #174684
SAFETY
