MacDon D50 - Page 24

169441 12 Revision D
ϭϬϰϬϭϱϯ
A
B
FE
A
B
C
F
D
A
C
B
D
B
B
1
2
A
E
C
Figure 1.20: Endsheets, Reel Arms, Backsheet – North American Headers
1 - D60 Headers Only 2 - D50 Headers Only
A - MD #42122 (Both Reel Arms) B - MD #174633 (Both Reel Arms) C - MD #142909 (Both Reel Arms)
D - MD #174436 (Both Ends) E - MD #113482 (Both Ends) F - MD #184371 (Double Knife: Both Ends; SIngle Knife: Left End Only)
SAFETY
