WINDROWER OPERATION
Form 169469/169470/169471 77 Revision C
l. Move float pins from location (G) to disengage
the float and store pins at location (H).
IMPORTANT
To prevent damage to the lift system when
lowering header lift linkages without a
header or weight box attached to
windrower, ensure that float engagement
pin is installed in storage location (H), and
not installed at hole location (G).
m. Remove pins (J) securing lift linkages to weight
box, and retain pins for attaching header to
windrower.
Disengage lift cylinder locks.
n. Start engine, lower weight box onto blocks and
back away.
o. Attach header to windrower. Refer to Section
6.5.1 Header Attachment.
p. Convert header into field position. See Header
Operator’s Manual for procedure.
