Manitowoc GROVE GMK6400 User Manual

Maintenance work on the carrier
7.4 Fuel system
16.11.2018
Maintenance manual 3 302 756 en 7 - 29
GMK6400
7.4.2 Changing fuel filter 1
Spare parts
and
tools
– Receptacle, about 5 l (1.5 gal); à p. 2 - 4.
Prerequisites – The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
– If the fuel is dirty: Reduce the maintenance interval.
Changing
• Place a receptacle underneath the filter.
• Close the valve – lever (1) at right angles to
the line.
• Open the screw (2) and the valve (3) and
drain the consumable.
s
M 3
Designation Quantity GROVE part no.
Filter 1 03322877
Gasket 1 03322879
Filter element 1 03328656
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
