Spare parts required for maintenance
11.4 Spare parts for the superstructure
11 - 8 3 302 756 en Maintenance manual
GMK6400
16.11.2018
11.4 Spare parts for the superstructure
Assemblies and spare parts
superstructure
GROVE
Part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
Hoists
Gasket 14 x 18 St DIN 7603
03043733 (2)
(if damaged)
Gasket 18 x 22 St DIN 7603 01927403 (4)
Gasket 14 x 18 St DIN 7603 03043733 2
Gasket 18 x 22 St DIN 7603 01927403 4
Gasket 26 x 31 St DIN 7603 03142181 4
Slewing gear
Gasket 10 x 13.5 Cu DIN 7603
00117125 (3) (if damaged)
Gasket 10 x 13.5 Cu DIN 7603 00117125 3
Gasket 14 x 20 Cu DIN 7603 00117132 3
Pump transfer case
Gasket 21 x 26 Cu DIN 7603
00117141 1 2
Oil filter
Packing set
03135866 At every oil change
when indicated
at the oil filter.
1
04161645 1
Hydraulic system
Filter 1 (only clean it)
Packing set
03325700 (1)
03135853 1
Filter 2 (only clean it)
Cover gasket
03317083 (1)
01372280 1
Filter 1
Packing set
03325700
At every oil change
and when a warning message
is displayed,
change the oil filter.
1
03135853 1
Filter 2
Cover gasket
03317083 1
01372280 1
Filter 3
Packing set
03046526 1
03137065 1
Oil tank cover gasket 140 / 90 x 3
03328286
1 item for every oil change
(if damaged)
Ventilation filter 03134932 2
