Manitowoc GROVE GMK6400

Maintenance work on the carrier
7.6 Transmission
7 - 52 3 302 756 en Maintenance manual
GMK6400
16.11.2018
7.6.6 Test drive
• Drive the truck crane for a distance of about 5 km (3 mi).
• Do not actuate the Intarder (lever on the steering column).
• Switch the engine off.
Checking the oil
level again
On the transmission
• After the test drive, check the oil level again
at the screw (1);
à Checking the transmission
oil level, p. 7 - 43.
• Top up the oil, if necessary; à Topping up
the oil, p. 7 - 48.
• Replace the seal and tighten the drain
plug
(1) to a torque of 60 Nm (44.2 lbf ft).
At the power take-off
• After the test drive, check the oil level
again
at the sight glass (1); à Checking the
oil level – power take-off, p. 7 - 44.
• Top up the oil, if necessary; à Topping up
the oil, p. 7 - 51.
