Maintenance work on the superstructure
8.15 Other maintenance work
8 - 102 3 302 756 en Maintenance manual
GMK6400
16.11.2018
8.15.3 Lubricating the crane cab door
Grease, spare
parts, tools
–Brush.
Prerequisites – The turntable is locked.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
Lubrication
• With the door closed, clean the rails (1)
outside.
• Lubricate the rails (1) lightly with a brush.
• Open the door completely using the
handle
(2) – the door locks in place.
• Clean the rails (3).
• Lubricate the rails (3) and the rollers (4)
lightly with a brush.
• Pull the unlocking device (5).
• Check if the door moves smoothly on the
rails and if it locks easily.
If the door is sluggish or does not close properly, have it adjusted by
Manitowoc Crane Care or an authorised GROVE-dealer.
M 12
Designation GROVE part no.
Grease: RHUS 2 AF, 1 kg can 03325215
