Maintenance work on the carrier
7.11 Suspension
7 - 80 3 302 756 en Maintenance manual
GMK6400
16.11.2018
7.11.2 Suspension struts – checking the fastening
Spare parts
and
tools
– Torque wrench for torques of up to 900 Nm (664 lbf ft).
Prerequisites – The truck crane must be raised on outriggers; à Operating manual.
– The engine must not be running and must be secured against unauthor-
ised use; Ã p. 2 - 3.
– The wheels must have been removed.
• Check that the bolts on all suspension struts are fitted tightly;
à Special torques, p. 10 - 2:
1 on the upper bracket,
2 on the lower bracket,
3 on the lower flange,
4 on the half shells for the steering lever.
