Manitowoc GROVE GMK6400 User Manual

Maintenance work on the carrier
7.8 Axle lines
16.11.2018
Maintenance manual 3 302 756 en 7 - 61
GMK6400
7.8.4 Axle centre drives – changing the oil
Oil, spare parts,
tools
– Receptacle, about 20 l (5.0 gal); à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspec-
tion pit.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
s
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specifications
Classification
GROVE part no.
Axle line 1:
14.0 (3.7)
Axle line 2:
15 (4.0)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SAE 90
ISO - VG 220
00552891
Designation Quanti-
ty
GROVE part no.
Gasket 30 x 36 Cu DIN 7603 2 00117151
Gasket 24 x 29 Cu DIN 7603 2 00117145
Gasket 36 x 42 Cu DIN 7603 2 01371208
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
