Manitowoc GROVE GMK6400 User Manual

Maintenance work on the carrier
7.7 Transfer case
16.11.2018
Maintenance manual 3 302 756 en 7 - 53
GMK6400
7.7 Transfer case
• Comply also with the running-in regulations; à p. 4 - 1.
7.7.1 General inspection
• Investigate any unusual noises made by the transfer case.
• Check the transfer case and the connections for leaks. In the event of
leaking consumables;
à Checking the oil level, p. 7 - 53.
• Check that pipes and hoses are tightly connected and undamaged.
If any damage is found, report it to Manitowoc Crane Care or an authorised
GROVE dealer or an authorised specialist workshop.
7.7.2 Checking the oil level
Spare parts
and
tools
Prerequisites – The truck crane must be raised on outriggers or parked over an inspec-
tion pit.
– The engine must not be running and must be secured against unauthor-
ised use; à p. 2 - 3.
s
W
M 1
Designation Quantity GROVE part no.
Gasket 30 x 36 Cu DIN 7603 1 00117151
