Maintenance work on the carrier
7.5 Exhaust system with exhaust emission control
7 - 36 3 302 756 en Maintenance manual
GMK6400
16.11.2018
7.5.1 Checking the AdBlue tank level
Checks The warning lamp for checking the AdBlue system is located on the instru-
ment panel in the driver's cab, a gauge for checking the AdBlue tank level is
located on the ECOS display.
H
The tank has a maximum filling volume of about 40 l (10.5 gal). Depending
on where the truck crane is used, it may be sensible to carry additional
canisters of AdBlue.
• Start the engine and check the lamp (1) after starting the engine:
– If the lamp goes out, the AdBlue level in the tank is sufficient.
– If the lamp lights up, the level in the AdBlue tank is on reserve.
– If the lamp flashes, the AdBlue tank is empty.
• Check the AdBlue level in the tank via the display (1).
• Refill the tank when the AdBlue level falls below about 10 l (2.6 gal) at the
latest – and/or if the lamp lights up.
7.5.2 Filling up with AdBlue
Consumable
and
tools
– As required: 2 canisters of about 20 l (5 gal) each; à p. 2 - 4.
Prerequisites – A service station with a filling pump for AdBlue can be used, or AdBlue
can be filled manually from canisters.
– The engine must not be running and must be secured against unauthor-
ised use; Ã p. 2 - 3.
AdBlue
in litres (gal)
Specifications
Classification
GROVE part no.
40 (10.5) DEF (Diesel Exhaust Fluid);
e.g. AdBlue.
03140555
