Manitowoc GROVE GMK6400

Maintenance work on the carrier
7.8 Axle lines
16.11.2018
Maintenance manual 3 302 756 en 7 - 57
GMK6400
7.8 Axle lines
• Comply also with the running-in regulations; à p. 4 - 1.
Overview There are different drive systems on the 6 axle lines.
Driven axle lines Drive system
1st Yes; permanent Axle centre drive, drive shafts,
final drives
2nd Yes; permanent Axle centre drive, drive shafts,
final drives
3rd No –
4th Yes; connectable Hydraulic drives,
Final drives
5. Yes; connectable Hydraulic drives,
Final drives
6. No –
