Maintenance work on the carrier
7.15 Central lubrication system
7 - 108 3 302 756 en Maintenance manual
GMK6400
16.11.2018
Topping up
Fill the grease container as follows:
• Switch on the ignition.
• Remove the cap (3).
• Connect the filling pump to the connec-
tion (1) or (2).
• Press button (4) once for about 2 seconds.
Intermediate lubrication will be triggered.
• Fill the grease container up to the Max.
marking.
• Remove the filling pump, wipe away any
excess grease and close the holes.
S
Risk of damage to the central lubrication system!
Cleanliness is of the utmost importance when handling grease and filling
pumps.
Do not remove the caps from the opening and filling pump until immedi-
ately before refilling the grease. This prevents dirt particles from getting
into the grease and damaging the central lubrication system.
1 Filling pump tool set:
You must install the connector from the
toolbox.
2 Filling pumps for lubrication nipples
