Installing & Configuring PhotoPRINT Server Configuring the Software
Sprinter User's Manual 13-11
14. Ensure that there is sufficient capacity the selected directory (e.g.,
C:/Temp)
15. Click the C
OLOR tab.
The C
OLOR tab appears (Figure 13-17).
Each color channel is represented by a slider that increases or
decreases the ink density.
Figure 13-17: Setup Properties Window – Color Tab
16. If required, edit the values in each box, to ensure exact matching
between channels.
The settings in the C
OLOR tab will not show in the job preview.
A
LL allows quick adjustments of all the color channels as a group.
C
ONTRAST adjusts the contrast of the image.
R
ESET restores the values and settings to their original state.
17. Click A
PPLY to confirm your settings and click OK.
Before importing a file, you must both select the required Setup icon and
check its corresponding option box.
