Power supply 109

Power supply

Included on the motherboard with the Matrox 4Sight

integrated unit is an external power supply with the following

specifications:

■ Input: 100 ~ 240 V

■ Output: 12 V

, 2.5 A (30 W)

■ Auto-resettable fuse
