Matrox 4Sight - IEEE 1394 Ports

IEEE 1394 ports 39
To connect your camera to the external input connector of a
Meteor-II/Multi-Channel on a Matrox 4Sight unit, use the
optional DBHD44-to-8BNC cable as follows:
IEEE 1394 ports
The IEEE 1394 ports allow you to connect to any IEEE 1394
DCS-compliant camera in an IEEE 1394 tree topology. To
connect your IEEE 1394 devices you use a 6-wire IEEE 1394
cable.
For further information, consult:
■ Anderson, Don. FireWire System Architecture. Reading,
Massachusetts: Mindshare Inc., 1998.
■ Henehan, Burke. "1394 Firewire Hardware Design
Considerations." Multimedia Systems Design
Mar. 1998.
■ http://www.msdmag.com
DBHD44-to-8BNC cable
Wires Signals Expected Input
Red VID1_IN1 Analog Video Input1, R1
Green VID1_IN2 Analog Video Input2, G1
Blue VID1_IN3 Analog Video Input3, B1
Black SYNC_IN SYNC input
Gray OPTOTRIG External trigger input
White VID2_IN1 Analog Video Input4, R2
Yellow VID2_IN2 Analog Video Input5, G2
Purple VID2_IN3 Analog Video input6, B2
