38 Chapter 2: Connecting and configuring external peripherals to the unit
that comes pre-installed as the first PC/104-Plus board in
Matrox 4Sight, has been modified slightly. If you initially
purchase your Matrox 4Sight without a Matrox Meteor-II board
and then need to add one later, this point will be crucial in
ordering the appropriate Matrox Meteor-II board. The pin outs
for this connector are detailed in Appendix D.
Connect your camera to the external input connector of a
Matrox Meteor II/Standard on the Matrox 4Sight unit using
the optional DBHD44-to-13BNC cable as follows:
Note that you can also connect to the external input connector
of the Matrox Meteor-II/Standard on the Matrox 4Sight unit
using the DBHD44-to-8BNC cable. In this case, use the color
coding of the wires described in the first eight rows of the above
table.
DBHD44-to-13BNC cable
Wires Signals Expected Input
Red VID_IN1 Analog Video Input1 or Y1
Green VID_IN2 Analog Video Input2 or C1
Blue VID_IN3 Analog Video Input3 or Y2
Black VID_IN4 Analog Video Input4 or C2
Gray OPTOTRIG External trigger input
White VID_IN5 Analog Video Input5 or C4
Yellow VID_IN6 Analog Video Input6 or Y3
Purple VID_IN7 Analog Video Input7 or C3
Brown VID_IN8 Analog Video Input8 or Y4
Light blue VID_IN9 Analog Video Input9 or Y5
Orange VID_IN10 Analog Video Input10 or C5
Pink VID_IN11 Analog Video Input11or Y6
Light green VID_IN12 Analog Video Input12 or C6
