168 Appendix D: Technical reference
Matrox 4Sight technical reference
Motherboard
■ EBX form factor (8” x 5¾” or 20.32cm x 14.61cm).
■ National Semiconductor® Geode™ GXLV processor running
at 266 MHz.
■ Up to 128 Mbytes of SDRAM via 168-pin DIMM slot.
■ Can output to a VGA monitor, TV, VCR, or flat panel
1
.
■ Support for non-destructive overlay and 16-bit stereo
audio I/O.
■ DiskOnChip
®
(optional) and 256 Kbyte flash BIOS.
■ 10/100 Mbit/sec Ethernet port.
■ Three 400 Mbit/sec IEEE 1394 ports.
■ Two RS-232 serial ports, parallel port, keyboard port, mouse
port, and floppy drive interface
1
.
■ 20 LVTTL or TTL compatible I/Os with interrupt-generation.
■ Supports up to three PC/104-Plus
™
boards.
Chassis
2
■ Integrated fan rated at 9-12 cfm (0.25-0.34 m
3
/min).
Optional hard drive
2
■ 2.5” diameter, mounted inside chassis, UltraDMA support.
■ Resistant to shocks.
Power supply
2
■ Input: 100 ~ 240 Vac; output: 12 Vdc, 2.5 A (30 W).
■ External to chassis.
1. Accessible via motherboard only.
2. Available with the Matrox 4Sight integrated unit.
