34 Chapter 2: Connecting and configuring external peripherals to the unit
Connect the wires of the cable as follows:
Configuring your
network connection
To configure a network connection under
Windows NT Embedded, you can use NTConfig to join a
domain on a LAN, to set the address allocation mode (static or
dynamic IP), and to set the ethernet connection type. These
options are available in NTConfig by clicking on the Network
Settings... button in the main NTConfig dialog box and
choosing the appropriate network configuration options.
RJ45
Left-side
function
Left-side
RJ 45cable-
connector
pin-number
Right-side
RJ 45 cable-
connector
pin-number
RJ45
Right-side
function
Wire 1 TX+ 1 3 RX+
Wire 2 TX- 2 6 RX-
Wire 3 RX+ 3 1 TX+
Wire 4 BD1+ 4 7 BD2+
Wire 5 BD1- 5 8 BD2-
Wire 6 RX- 6 2 TX-
Wire 7 BD2+ 7 4 BD1+
Wire 8 BD2- 8 5 BD1-
Transmitter
Receiver
Transmitter
Receiver
PC 1
Matrox 4Sight
Peer-to-peer connection for the Matrox 4Sight.
