FOCKE MELER GLUING SOLUTIONS
10-8
SPARE PARTS LIST
E. CHASSIS ASSEMBLY
Nº Ref. Description
1 (*) 150117140 Micron electrical cabinet door casing
2 150113290 Electrical cabinet casing assembly without warning light
2 150113360 Electrical cabinet casing assembly with warning light
3 150113300 Micron 5 tank housing assembly
3 150113310 Micron 10 tank housing assembly
3 150113320 Micron 20 tank housing assembly
3 150114950 Micron 35 tank housing assembly
4 150113330 Micron 5 tank cover assembly
4 150113340 Micron 10 tank cover assembly
4 150113350 Micron 20 tank cover assembly
4.1 150114960 Micron 35 tank cover assembly
(*) For equipments with two motors, ask for the reference.
1
2
4
4.1
3
