Meler Micron 5 - Components for Dual Motor-Pump Models

FOCKE MELER GLUING SOLUTIONS
2-4
INTRODUCTION
Main components Micron gear with two motor-pumps
Marking of the Micron gear components is the same for all models with two
motor-pumps. In this case the pictures refers to the 20-liter model.
For each motor-pump assembly installed:
1. Pumping control card 1
2. Pumping control card 2
3. Pressure regulator 1
4. Pressure regulator 2
5. Hoses output 1
6. Hoses output 2
7. Gear motor 1
8. Gear motor 2
1
7
3
2
8
4
5
6
