INSTALLATION
3-1
MA-5079-ENG MICRON GEAR ADHESIVE MELTER
3. INSTALLATION
Warning: The melters are equipment with current technology and with certain
foreseeable risks. Therefore, only allow qualified personnel with enough
training and experience to use, install or repair this equipment.
Introduction
The melters of this serie are delivered with all the materials necessary for
their installation. However, some components must be provided by the user
himself, according to the location and connections in each particular installation:
Anchoring screws for the melter equipment.
Power cord and plug for electrical power.
Pneumatic pipe and connection to the compressed air system.
Multicore cable for external electrical control.
Optionally, a gas ventilation system.
Installation requirements
Before installing Micron gear series melter equipment, we must make
sure that the space assigned to it permits installing, connecting and using
the entire system. Similarly, we must check to see that the electrical
and pneumatic supplies meet the necessary requirements of the melter
equipment being installed.
Free space
Item Description Dimensions
A EQUIPMENT LENGTH
5L 730mm
10L 730mm
20L 730mm
35L 740mm
B EQUIPMENT WIDTH
5L 360mm
10L 360mm
20L 400mm
35L 450mm
C EQUIPMENT HEIGHT
5L 630mm
10L 630mm
20L 670mm
35L 830mm
D EQUIPMENT HEIGHT WITH LID OPEN
5L 775mm
10L 885mm
20L 1025mm
35L 1215mm
E EQUIPMENT LENGTH WITH ELECTRICAL CABINET OPEN
5L 840mm
10L 920mm
20L 925mm
35L 990mm
F
LENGTH OF THE EQUIPMENT WITH BRACKET FOR ELECTRIC
CABINET VARIABLE FREQUENCY DRIVES IN LOWERED POSITION
5L 1200mm
10L 1280mm
20L 1285mm
35L 1355mm
