MA-5079-ENG MICRON GEAR ADHESIVE MELTER
6-5
TROUBLESHOOTING
Causes Checking Comments Actions
Equipment power
supply malfunction.
Check voltage between
phases and neutrals.
Check voltage in CN4
connector.
Voltages will vary depending on
power supply.
Check wiring. Check net
power supply. Change
electric supply cable.
Ribbon cable
malfunction.
Check ribbon cable
(CN11).
Check the connections between the
cable and the board.
Change ribbon cable.
Manifold fuse blown.
Check fuse continuity (F02
in CN6).
Release the fuse to check it out with
the system turned off.
Change fuse.
Power board
damaged.
Check voltage in the CN6
connector (pins 1 and 3).
Correct if voltage is around 230V and
DL1 is on.
Check connector wiring,
position. Change board.
Power supply wire to
the tank damaged.
Check voltage in the CN6
connector (pins 1 and
3) and in the manifold
terminal strip.
If voltage around 230V in the
connector, but not in the terminal
strip, the wire is damaged.
Check connections
between the connector
and the terminal strip.
Change wire.
Heating element
shortcircuited or
blown.
Check voltage in the
terminal strip.
Correct if voltage equals to 230V.
Change the heating
element.
Manifold
The manifold does not heat (Micron, 1 geared motor)
The manifold does not heat (Micron, 2 geared motors)
Causes Checking Comments Actions
Equipment power
supply malfunction.
Check voltage between
phases and neutrals.
Check voltage in CN4
connector.
Voltages will vary depending on
power supply.
Check wiring.
Check net power supply.
Change electric supply
cable.
1/2 Manifold fuse
blown.
Check fuse continuity (*).
( 1 )
Release the fuse to check it out with
the system turned off.
Change fuse.
Tarjeta de potencia
estropeada.
Check voltage in the
connector (pin (*) and (*)
in CN9).
( 2 )
Correct if voltage is around 230V and
DL(*) is on.
Check connector wiring,
position. Change board.
1/2 Power supply wire
to the tank damaged.
Check voltage in the CN9
connector (pin (*) and (*))
and in the terminal strip.
(3 )
If voltage around 230V in the
connector, but not in the terminal
strip, the wire is damaged.
Check connections
between the connector
and the terminal strip.
Change wire.
1/2 Heating element
shortcircuited or
blown.
Check voltage in the
terminal strip.
Si hay 230V en la regleta y no
calienta el distribuidor, la resistencia
está dañada.
Change the heating
element.
Causes Checking Comments Actions
Power board
malfunction.
Check the power board. LED indicator (DL1) remains off. Change power board.
Control board
malfunction.
Check the control board. LED indicator (DL1) remains on. Change control board.
The manifold does not stop heating (Micron, 1 geared motor)
