INTRODUCTION
2-3
MA-5079-ENG MICRON GEAR ADHESIVE MELTER
Main components
1. Front control card.
2. Access door to the electric/pneumatic area.
3. Tank access lid.
4. Main switch ON/OFF.
5. Pumping control card.
6. Air pressure gauge for pneumatic by-pass valve.
7. Pressure regulator of by-pass valve (opcionally pneumatic or mechanical
regulator).
8. Access door to filter and purge valve.
9. Hose output distributor (up to 4 hydraulic connections by motor-pump
assembly).
10. Compressed air hook-up (max. 6 bar).
11. Hose-applicator electrical connections.
12. Characteristics plate.
12
11109
4
7 8
5
6
1 2
3
