MA-5079-ENG MICRON GEAR ADHESIVE MELTER
6-11
TROUBLESHOOTING
Micron 1 geared motor
Note Applicator 1 Applicator 2 Applicator 3 Applicator 4 Applicator 5 Applicator 6
(1) CN9 / P1 CN9 / P2 CN10 / P3 CN10 / P4 CN11 / P5 CN11 / P6
(2) F04 F05 F06 F07 F08 F09
(3) CN9 / P1 / DL4 CN9 / P2 / DL6 CN10 / P3 / DL8 CN10/ P4 /DL10 CN11/ P5 /DL12 CN11/ P6 /DL14
(4) DL4 DL6 DL7 DL10 DL12 DL14
(5) CN2 CN3 CN4 CN5 CN6 CN7
Note Applicator 1 Applicator 2 Applicator 3 Applicator 4
(1) CN10 / P3 CN10 / P4 CN11 / P5 CN11 / P6
(2) F06 F07 F08 F09
(3) CN10 / P3 / DL8 CN10/ P4 /DL10 CN11/ P5 /DL12 CN11/ P6 /DL14
(4) DL7 DL10 DL12 DL14
(5) CN4 CN5 CN6 CN7
Micron with 2 geared motors
