TECHNICAL CHARACTERISTICS
Tank capacity
Pumping rate
simple pump
double pump (per output
Melting rate
Number of outputs
Temperature range
(optional)
Temperature control
Max. working pressure (at 6 bar)
Max. installation power (at 230V)
with a simple pump/2 outputs
with a simple pump/4 outputs
with a simple pump/6 outputs
with two simple pumps/2 outputs
with two simple pumps/4 outputs
External requirements
Electrical requirements
(optional)
Workplace temperature
Dimensions
Weight
with one pump
(*) Under standard conditions
19,7 liters
1, 2.5, 4, 8 cc/rev (*)
2x0.93, 2x1.86, 2x3.71, 2x4.8 cc/rev (*)
19,0 kg/h (*)
2, 4 or 6 with one pump
2 or 4 with two pumps
40 to 200°C (104 to 392°F)
40 to 230°C (104 to 450°F)
RTD ±0.5°C (±1°F)
Pt-100 or Ni-120
80 bar (1160 psi)
1 x 7,3KW/ 3 x 4,5KW
1 x 9,7KW/ 3 x 4,5KW
1 x 12,1KW/ 3 x 4,5KW
1 x 8,7KW/ 3 x 3,9KW
1 x 11,1KW/ 3 x 5,1KW
Temperature ok output
Low level output (optional)
External stand-by activation
Outputs disabled external control
Motor start up input
Motor speed control input
Failures in pumping card output
LN ~ 230V 50/60Hz + PE
3N ~ 400V 50/60Hz + PE
3 ~ 230V 50/60Hz + PE
3 ~ 400V 50Hz + PE with transformer base
0 a 40°C
730 x 400 x 670 mm
730 x 400 x 1022 (lid open)
90 kg (empty)
37,4 liters
1, 2.5, 4, 8 cc/rev (*)
2x0.93, 2x1.86, 2x3.71, 2x4.8 cc/rev (*)
30,0 kg/h (*)
2, 4 or 6 with one pump
2 or 4 with two pumps
40 to 200°C (104 to 392°F)
40 to 230°C (104 to 450°F)
RTD ±0.5°C (±1°F)
Pt-100 or Ni-120
80 bar (1160 psi)
1 x 7,8KW/ 3 x 3,8KW
1 x 11,2KW/ 3 x 5,0KW
1 x 13,6KW/ 3 x 4,0KW
1 x 10,2KW/ 3 x 3,9KW
1 x 12,6KW/ 3 x 5,1KW
Temperature ok output
Low level output (optional)
External stand-by activation
Outputs disabled external control
Motor start up input
Motor speed control input
Failures in pumping card output
LN ~ 230V 50/60Hz + PE
3N ~ 400V 50/60Hz + PE
3 ~ 230V 50/60Hz + PE
3 ~ 400V 50Hz + PE with transformer base
0 a 40°C
740 x 450 x 830 mm
740 x 450 x 1215 (lid open)
145 kg (empty)
