90-826148R2 MARCH 1997 ELECTRICAL - 2D-21
IMPORTANT: On installations where gauge
options will not be used, tape back and isolate
any unused wiring harness leads.
52654
a
e
f
g
i
j
m
o
BATT
GND
SENDER
STARBOARD INSTALLATION
k - Lanyard/Diode
l - Y Harness
m- Power Trim Harness Connector
n - Connect Wires Together with Screw and Hex Nut (4
Places);Apply Quicksilver Liquid Neoprene to Connections
and Slide Rubber Sleeve over Each Connection.
o - Lead to Visual Warning Kit
