Mercury 30 Service Manual

90-826148R2 MARCH 1997 ATTACHMENTS/CONTROL LINKAGE - 7A-9
Bottom Cowl/Shift Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
45
1 PLUG-Stop Switch
46
1 RETAINER
47
1 STOP SWITCH
48
1 LANYARD STOP SWITCH
49
1 GROMMET
50
1 SWITCH (ELECTRIC HANDLE)
51
1 SEAL-Throttle Cable
52
1 SEAL-Throttle Cable
5
3
1 BOTTOM COWL (BLACK)
5
3
1 BOTTOM COWL (GRAY)
54
1 PLUG-Shift Lever
55
1 SHIFT HANDLE
5
6
1 GROMMET
5
6
1 GROMMET (SPLIT - POWER TRIM)
57
1 PLUG-Warning Alarm (ELECTRIC)
58
1 SEAL-Warning Horn
59
1 ALARM
60
1 WASHER
61
1 SCREW (M5 x .8 x 12)
Drive Tight
62
1 SWITCH ASSEMBLY (POWER TRIM)
63
1 PLUG-Trim Switch
64
1 RETAINER
65
1 SCREW (M10-16 x 1/2 Self Tap)
75 8.5
66
1 SCREW (M5 x 16)-Interlock Cable
67
1 SCREW (M6 x 16)
100 11.3
68
1 CAM-Latch
69
1 WAVE WASHER
70
1 BUSHING
71
1 FITTING-Telltale
72
2 STA-STRAP
73
1 TUBING (15”)
74
1 BUSHING
7
5
1 LEVER-Cowl Latch (BLACK)
7
5
1 LEVER-Cowl Latch (GRAY)
76
4 SCREW (M6 x 25)
100 11.3
77
4 BUSHING
78
4 GROMMET
