Mercury 30 Service Manual

MID-SECTION - 5A-390-826148R2 MARCH 1997
Clamp Bracket Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 CLAMP BRACKET (BLACK) PORT SHORT
1
1
CLAMP BRACKET (GRAY) 1 lower mounting hole
1
1 CLAMP BRACKET (BLACK) PORT LONG
1 CLAMP BRACKET (GRAY) 3 lower mounting holes
1 CLAMP BRACKET (BLACK) STBD. SHORT
2
1 CLAMP BRACKET (GRAY) 1 lower mounting hole
2
1 CLAMP BRACKET (BLACK) STBD. LONG
1 CLAMP BRACKET (GRAY) 3 lower mounting holes
3 2 THUMB SCREW ASSEMBLY
4 2 HANDLE
5 2 RIVET MANUAL
6 2 WASHER
7 2 SCREW (Hex shoulder) 60 6.8
8 1 NUT (M10 x 1.5) 28 37.9
9 1 WASHER
10 1 ANODE
11 2 WASHER
12 2 SCREW (M6 x 25) 60 6.8
13 1 STUD (M10 x 277)
14 1 SPACER
4 NUT (.500-20) (LONG) Drive Tight
1
5
2 NUT (.500-20) (SHORT) (TOP) Drive Tight
1
5
2 NUT (M10 x 1.5) (SHORT) (BOTTOM) Drive Tight
4 WASHER (LONG)
1
6
2 WASHER (SHORT) (TOP)
1
6
2 WASHER (SHORT) (BOTTOM)
4 SCREW (.500-20 x 4”) (LONG)
1
7
2 SCREW (.500-20 x 4”) (SHORT) (TOP)
1
7
2 SCREW (SHORT) (BOTTOM)
18 1 SEAL KIT
19 1 O RING
20 1 SPACER
21 1 NUT (M10 x 1.5) 28 37.9
22 1 WASHER
23 1 TILT LOCK PIN
24 1 SPRING
25 1 LEVER-Shallow Water Drive
26 1 ROLL PIN
27 1 CAP-Tilt Stop Pin
28 1 ROLL PIN
29 1 BUSHING
30 1 PIN-Tilt Stop
31 1 BUSHING (PLASTIC)
32 1 ROD-Shallow Water Drive
33 1 BUSHING (PLASTIC)
34 1 BUSHING
35 1 ARM
36 1 LINK ROD
37
1 SPRING
