Mercury 30 Service Manual

2C-0 - ELECTRICAL 90-826148R2 MARCH 1997
Table of Contents
Page
Specifications 2C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Tools 2C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tiller Handle Model
(S/N-0G589999 & Below) 2C-2. . .. . . . . . . . . . . . . . . . . .
Timing Adjustments 2C-3. . . . . . . . . . . . . . . . . . . . . . . . . .
Tiller Handle Model with
Mechanical Spark Advance
(S/N-0G590000 & Above) 2C-4. . .. . . . . . . . . . . . . . . . . .
Timing And Maximum Spark Advance
Adjustments - Mechanical Spark Advance
Models 2C-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting Idle Timing 2C-5. . . . . . . . . . . . . . . . . . .
Adjusting Maximum Spark Advance 2C-6. . . . . .
Shift Link Rod Installation and Adjustment
to Engine 2C-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle Cable Installation 2C-7. . . . . . . . . . . . . . . . . . . . .
Oil Pump Adjustment 2C-8. . . . . . . . . . . . . . . . . . . . . . . . .

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
