Mercury 30 Service Manual

90-826148R2 MARCH 1997 ATTACHMENTS/CONTROL LINKAGE - 7A-7
Bottom Cowl/Shift Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SPRING-Detent
2 2 SPRING-Backing
3 1 PLATE
4 2 SCREW (M5 x 14) 75 8.5
5 1 STRAP-Horizontal Shift Shaft
6 1 SCREW (M6 x 1 x 16) 100 11.3
7 1 CLAMP-Horizontal Shift Shaft
8 2 SCREW (M6 x 1 x 30) 100 11.3
9 1 SWITCH
10 2 SCREW (M3 x .5 x 20) Drive Tight
11 1 PLATE-Switch
12 1 CAP-Intermediate Lever
13 1 SCREW (M6 x 16) 100 11.3
14 1 BUSHING
15 1 LEVER-Intermediate
16 1 INSERT
17 1 PIN
18 1 BUSHING
19 1 NYLINER
20 1 RETAINER
21 1 WASHER
22 1 NUT (M6) Drive Tight - But
23 1 NUT (M6)
Joint Must Be Free
24 1 WASHER
25 1 LINK-Shift
26 1 NYLINER
27 1 HARNESS ELECTRIC HANDLE
28 1 HARNESS ADAPTOR
29 1 SHIFT SHAFT-Horizontal
30 1 LEVER-Interlock Actuating
31 1 COTTER PIN
32 1 SCREW (M10-16 x .38 Self Tap)
33 1 CABLE (BLACK-7 1/2”)
34 1 SHIFT ROD
35 2 COTTER PIN
36 2 PIN-Shift Rod
37 2 LOCKWASHER
38 1 LEVER-Shift
39 1 WAVE WASHER
40 1 SCREW (M5 x .8 x 16)
41 1 LATCH
42 1 CUP
43 2 DRIVE SCREW
44 1 SEAL

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
