Mercury 30 Service Manual

90-826148R2 MARCH 1997 MANUAL STARTER - 8-3
Manual Start Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 SEAL-Handle rest
2
2 NUT (M6 x 1)
3
2
WASHER
4
2 SPACER-Handle rest
5
1 REST-Starter Handle
6
1 HANDLE-Starter
7
1 RETAINER
8
4 WING NUT
90 10.2
9
4 WASHER
10
4 GROMMET
11
4 BUSHING
12
4 GROMMET
13
4 WASHER
-
1 RECOIL STARTER (S/N-USA-0G239163/BEL-9864479 & BELOW)
-
1 RECOIL STARTER (S/N-USA-0G239164/BEL-9864480 & ABOVE)
14
1 HOUSING
15
1 RETAINING RING
16
1 BUSHING-Rope
17
1 LOCKWASHER
18
1 SPRING/KEEPER ASSEMBLY
19
1 SHEAVE-Starter
20
1 STARTER ROPE
21
1 SPRING
22
1 CAM
23
1 SCREW (1/4-20)
135 15.3
24
2 RETAINING RING
25
2 CAM
26
2 SPRING
27
3 SCREW (10-16 x 1 IN.)
28
1 RETAINER
29
1 CAM
3
0
1 LEVER (S/N-USA-0G239163/BEL-9864479 & BELOW)
3
0
1 LEVER (S/N-USA-0G239164/BEL-9864480 & ABOVE)
31
1 SPRING
32
1 CABLE-Interlock
33
1 SCREW (M5 x .8 x 16)
34
1 WASHER
35
1 SCREW (10-16 x .625)
36
1 COTTER PIN

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
