Mercury 30 Service Manual

MID-SECTION - 5A-1190-826148R2 MARCH 1997
Driveshaft Housing Components
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
30 1 SEAL-Exhaust Bucket
31 1 EXHAUST BUCKET
32 1 BUMPER-Trim Cover
33 1 SEAL-Exhaust Tube
34 1 SEAL-Idle Relief
35 6 SCREW (M10 x 110) 29 39.3
1 DRIVESHAFT HOUSING (SHORT-BLACK)
3
6
1 DRIVESHAFT HOUSING (SHORT-GRAY)
3
6
1 DRIVESHAFT HOUSING (LONG-BLACK)
1 DRIVESHAFT HOUSING (LONG-GRAY)
3
7
1 STUD (M10 x 1.5 x 50) (SHORT/LONG)
3
7
1 STUD (M10 x 1.5 x 114) (X-LONG)
38 2 SCREW (M8 x 1.25 x 120)
39 1 MOUNT (LOWER)
4
0
1 COVER-Mount (BLACK)
4
0
1 COVER-Mount (GRAY)
41 1 WASHER
42 1 NUT (M10) 40 54.2
43 2 SCREW (10-16 x .38)
44 1 SCREW (M8 x 1.25 x 65)
45 1 LOCKWASHER
46 1 CABLE ASSEMBLY
47 1 BUMPER (FRONT)
48 1 MOUNT (LOWER)
4
9
1 COVER-Mount (BLACK)
4
9
1 COVER-Mount (GRAY)
50 3 WASHER
51 3 NUT (M8 x 1.25) 240 20 27.1

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
