Mercury 30 Service Manual

90-826148R2 MARCH 1997 ATTACHMENTS/CONTROL LINKAGE - 7A-5
THROTTLE LINKAGE (S/N-0G590000 & ABOVE)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 BUMPER--Throttle Stop
2 1 WASHER
3 1 BUMPER--Throttle Stop
4 1 LEVER--Throttle Control
5 1 BALL--Threaded
6 1 BUSHING KIT
7 1 INSERT
8 1 SCREW (M10 x 45) 16.7 22.6
9 1 NUT (M6)
Drive Tight --
But Joint Must Move
Freely
10 1 WASHER
11 1 RETAINER
12 1 INSERT--Pin
13 1 PIN
14 1 LINK--Throttle Control
15 2 SOCKET--Ball
16 1 NUT
17 1
WASHER
18 1 SCREW (M6 x 16) 100 11.3
19 1 BRACKET-Throttle Cable
20 1 SPARK ARM
21 1 THROTTLE CAM
22 1 SPRING
23 1 BUSHING
24 1 WAVE WASHER
25 1 SCREW (M6 x 35)
26 1 SCREW (M5 x 35)
27 1 NUT
28 1 SPARK CONTROL LINK
29 2 SOCKET--Ball
30 1 NUT

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
