Mercury 30 Service Manual

FUEL SYSTEM - 3A-390-826148R2 MARCH 1997
FUEL PUMP (MANUAL)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 FUEL PUMP ASSEMBLY
2 1 DIAPHRAGM KIT
3 2 RUBBER CHECK VALVE
4 2 CHECK VALVE
5 2 RETAINER
6 1 SPRING
7 1 CAP
8 1 SPRING
9 1 CAP
10 1 GASKET--Boost
11 1 GASKET
12 1 DIAPHRAGM
13 1 GASKET--Pulse
14 1 BASE
15 1 PLATE
16 2 SCREW--pump to crankcase (M6 x 1 x 50) 55 6.2
17 2 SCREW--pump 55 6.2
18 1 FITTING
19 1 PRIMER BULB
20 2 HOSE (9-1/2 IN.)
21 1 SLEEVE
22 1 HOSE
23 AR STA-STRAP
24 1 HOSE (3-1/4 IN.)
25 1 INSULATOR
26 1 HOSE (MOLDED)
27 1 FUEL FILTER
28 1 BRACKET
29 1 NUT (M6 x 1) Drive Tight
30 1 HOSE (14-1/4 IN.)
31 1 FUEL CONNECTOR
32 1 SCREW 100 11.3

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
