Mercury 30 Service Manual

FUEL SYSTEM - 3A-590-826148R2 MARCH 1997
FUEL PUMP (ELECTRIC)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 FUEL PUMP ASSEMBLY
2 1 DIAPHRAGM KIT
3 2 RUBBER CHECK VALVE
4 2 CHECK VALVE
5 2 RETAINER
6 1 SPRING
7 1 CAP
8 1 SPRING
9 1 CAP
10 1 GASKET--Boost
11 1 GASKET
12 1 DIAPHRAGM
13 1 GASKET--Pulse
14 1 BASE
15 1 PLATE
16 2 SCREW--pump to crankcase (M6 x 1 x 50) 55 6.2
17 2 SCREW--pump (M5 x .8 x 40) 55 6.2
18 1 FITTING
19 1 CLAMP
20 1 SCREW (M6 x 16)
21 1 SOLENOID VALVE
22 2 STA--STRAP
23 2 HOSE (11 1/2 IN.)
2
4
1 SLEEVE (1/2 x 5 IN.)
2
4
1 SLEEVE (3/8 x 7-1/2 IN.)
25 AR STA--STRAP
26 1 TEE FITTING
27 1 HOSE (4 IN.)
28 1 HOSE (3-1/4 IN.)
29 1 HOSE
30 1 HOSE (3-1/4 IN.)
31 1 INSULATOR
3
2
1 HOSE (MOLDED)
3
2
1 TUBING (9 IN.)
33 1 TEE (DESIGN I)
34 1 CONNECTOR (DESIGN II)
35 1 TUBING (4 IN.)
36 1 CHECK VALVE
37 1 HOSE (1-1/2 IN.)
38 1 TUBING (1-1/4 IN.)
39 1 FUEL FILTER
40 1 BRACKET
41 1 NUT (M6 x 1) Drive Tight
42 1 HOSE (14 1/4 IN.)
43 1 FUEL CONNECTOR
44 1 SCREW
45 1 PRIMER BULB
46 2
HOSE (9-1/2 IN.) ELECTRIC HANDLE
4
7
AR SLEEVE (3/8 x 7-1/2 IN.)
4
7
1 SLEEVE (1/2 x 5 IN.)

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
