2-UpperShiftShaftLubrication
3
3-SwivelPinGreaseFittings
WARNING
Coreofsteeringcable(transomend)mustbeful-
lyretractedintocablehousingbeforelubricating
cable.Ifcableislubricatedwhileextended,hy-
drauliclockofcablecouldoccur.
WithcoreofRideGuideSteeringcable(transom
end)fullyretracted,lubricatetransomendofsteering
cablethrugreasefittingandexposedportionofcable
endwithQuicksilver2-4-CMarineLubricant.Lubri-
cateallpivotpointswithSAE30Wengineoil
.
ElectricandRemoteControlModels
4
5
6
TillerHandleModels
5
4-RideGuideSteeringGreaseFitting
5-TiltTube/Co-PilotGreaseFitting
6-SteeringLinkRodPivotPointLubrication
7
50551
7-PropellerShaftLubrication
