POWERHEAD - 4-790-826148R2 MARCH 1997
INDUCTION MANIFOLD
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1
INDUCTION MANIFOLD (S/N-0G380074/
BEL-9905360 & BELOW)
1
1
INDUCTION MANIFOLD (S/N-0G380075/
BEL-9905361 & ABOVE)
2 1 CHECK VALVE
3 1 FITTING (Barbed)
4 4
DOWEL PIN (Component of Ref #1) (S/N-0G380074/
BEL-9905360 & BELOW)
5 2 STUD (M6 x 1 x 44)
6 2 STUD (M6 x 1 x 55)(STUD ATTACHING)
7 2 SCREW (M6 x 40)(SCREW ATTACHING)
8 1 TUBING (12 1/2 IN.)
9
8
SCREW (M8 x 30) (S/N-OG380075/
BEL-9905361 & UP)
200 16.5 22.4
9
8 SCREW (M8 x 1.25 x 25 Hex flange head) 200 16.5 22.4
10 2 REED ASSEMBLY
11 2
TAB WASHER
S/N-USA-0G380074/BEL-(30)-9905360/
BEL-(40)-9905385 & BELOW
12 2 RETAINER--Reed (40 H.P.)
13 2 RETAINER--Reed (30 H.P.)
14 2 SCREW (M6 x 1 x 16 Hex head cap) 100 11.3
15 1 GASKET--Manifold
1
6
1 REED VALVE (30 H.P.) S/N-USA-0G380075/BEL-9905361 & ABOVE
1
6
1 REED VALVE (40 H.P.) S/N-USA-0G380075/BEL-9905386 & ABOVE
