POWERHEAD - 4-1190-826148R2 MARCH 1997
11. Thread lifting eye at least 5 turns into flywheel.
52689
a
a - Lifting Eye (P/N 91-90455)
12. Remove 6 bolts securing powerhead to drive
shaft housing.
52688
a
a
a - Bolt (6)
WARNING
DONOT leavepowerheadsuspended from hoist.
Powerhead should be installed on a suitable
stand or lowered to floor upon removal from
drive shaft housing to avoid personal injury or
damage to product.
13. Using suitable hoist, remove powerhead from
drive shaft housing.
52690
