Mercury 30 Service Manual

90-826148R2 MARCH 1997 MID-SECTION - 5B-3
POWER TRIM
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 POWER TRIM ASSEMBLY (S/N-USA-0G124404/BEL-9948794 & BELOW)
1
1 POWER TRIM ASSEMBLY (S/N-USA-0G124405/BEL-9948795 & ABOVE)
– 1 O RING KIT
2
1 SHOCK ROD ASSY. (S/N-USA-0G124404/BEL-9948794 & BELOW)
2
1 SHOCK ROD ASSY. (S/N-USA-0G124405/BEL-9948795 & ABOVE) 45 61
3 1 PILOT CHECK ASSEMBLY 120 13.6
4 1 TILT RELIEF VALVE ASSEMBLY 120 13.6
5 1 SUCTION SEAT ASSEMBLY 120 13.6
6 1 PUMP ASSEMBLY
7 1 BALL & SPRING
8 1 SCREW 70 7.9
9 1 FILTER
10 1 O RING
11 1 MOTOR ASSEMBLY
12 4 SCREW 80 9.0
13 4 WASHER
14 1 CABLE
15 1 O RING
16 1 COUPLER
17 1 MEMORY PISTON
18 1 MANUAL RELEASE VALVE ASSEMBLY Drive Tight
19 1 RESERVOIR PLUG Drive Tight
– 1 HARNESS ASSEMBLY–Trim
20 1
HARNESS ASSEMBLY–Trim DESIGN I
21 2 RELAY
22 2 BRACKET
23 2 GROMMET
24 2 SCREW (M6 x 1 x 25)
25 1 SCREW (10-16 x 5/8–Self-Tap)
26 1 BRACKET
27 1 HARNESS-Trim
28 2 SCREW (M6 x 25) DESIGN II
29 2 RELAY ASSEMBLY
30 2 BRACKET
31 2 GROMMET
32 2 BUSHING
A - TORQUE CYLINDER CAP TO 45 LB. FT. (61 N⋅M)
B - TORQUE SCREW TO 80 LB. IN. (9.0 N⋅M)
C - TORQUE SCREW TO 70 LB. IN. (7.9 N⋅M)
D - TORQUE PILOT CHECK PLUG TO 120 LB. IN. (13.6 N⋅M)
E - TORQUE TILT RELIEF PLUG TO 120 LB. IN. (13.6 N⋅M)
F - TORQUE SUCTION SEAT PLUG TO 120 LB. IN. (13.6 N⋅M)
G - TORQUE SHOCK PISTON TO 45 LB. FT. (61 N⋅M)

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
