90-826148R2 MARCH 1997 MID-SECTION - 5C-3
CLAMP BRACKET (GAS ASSIST TRIM)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1
1 CLAMP BRACKET (BLACK) PORT
1
1
CLAMP BRACKET (GRAY)
2
1 CLAMP BRACKET (BLACK) STARBOARD
2
1 CLAMP BRACKET (GRAY)
3 2 THUMB SCREW ASSEMBLY
4 2 HANDLE
5 2 RIVET MANUAL
6 2 WASHER
7 2 SCREW (Hex shoulder) 60 6.8
8 1 ANODE
9 2 WASHER
10 2 SCREW (M6 x 25) 60 6.8
11 2 NUT (.500-20) Drive Tight
12 2 WASHER
13 2 SCREW (.500-20 x 4 IN.)
14 1 DECAL-Tilt Lock
15 1 DECAL-Warning
16 1 CAP--Tilt Stop Pin
17 1 ROLL PIN
18 1 BUSHING
19 1 PIN--Tilt Stop
20 1 TRIM, Hydraulic assist
21 1 CABLE
22 1 TILT LEVER
23 1 TILT KNOB GAS ASSIST TRIM
24 1 LEVER ARM
25 1 WAVE WASHER
26 1 ROLL PIN (1/8 x 3/4 IN.)
27 1 LINK
28 1 NUT
29 1 ANCHOR PIN (14MM)
30 2 BUSHING
31 2 BUSHING GAS ASSIST TRIM &
32 2 WASHER POWER TRIM MOUNTING
33 2 NUT
34 2 SCREW (M10 x 40)
35 2 WASHER
36 2 NUT
37 1 TILT LOCK PIN NON POWER TRIM
38 1 SPRING
