Mercury 30 Service Manual

LOWER UNIT - 6-790-826148R2 MARCH 1997
Gear Housing Components (Drive Shaft)
R
E
F
.
TORQUE
R
E
F
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
-- 1 GEAR HOUSING (SHORT-BLACK)
-- 1 GEAR HOUSING (LONG-BLACK)
-- 1 GEAR HOUSING (X-LONG-BLACK)
-- 1 GEAR HOUSING (SHORT-GRAY)
-- 1 GEAR HOUSING (LONG-GRAY)
-- 1 GEAR HOUSING (X-LONG-GRAY)
1
1 GEAR HOUSING (BASIC-BLACK)
1
1 GEAR HOUSING (BASIC-GRAY)
2 1 SEAL/PLATE KIT
3 1 PLATE (Part Of Ref #2)
4 1 SCREW (.375-16 x .25) 55 6.2
5 1 WASHER-Sealing
6 1 DRAIN SCREW (MAGNETIC) 55 6.2
7 1 WASHER-Sealing
8 1 NUT 50 67.8
9 1 PINION GEAR
10 1 BEARING ASSEMBLY-Roller
11 1 CUP (Part Of Ref #10)
12 4 SCREW (M6 x 16) 60 6.8
13 1 WATER PUMP ASSEMBLY
14 1 SEAL-Water Tube (SHORT/LONG)
15 1 WASHER
16 1 KEY
17 1 WASHER
18 1 GASKET
19 1 GASKET (LOWER)
20 1 FACE PLATE
21 1 IMPELLER
22 1 WATER PUMP BASE ASSEMBLY
23 1 SEAL-Oil
24 1 SEAL-Oil
25 1 O RING
26 1 BALL BEARING
1 DRIVESHAFT (SHORT)
2
7
1 DRIVESHAFT (LONG)
2
7
1 DRIVESHAFT (X-LONG)
28 1 NUT (INCLUDED WITH REF #35)
29 1 CABLE TIE
30 1 BOOT-Shift Shaft
31 1 RETAINER-Shift Shaft
32 1 O RING
33 1 O RING
34 1 WASHER
1 SHIFT SHAFT (SHORT)
3
5
1 SHIFT SHAFT (LONG)
3
5
1 SHIFT SHAFT (X-LONG)
36 1 WASHER
37 1 ROLL PIN
38 1 CAM-Shift
39 1 PIN

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
