Mercury 30 Service Manual

90-826148R2 MARCH 1997 ELECTRICAL - 2A-3
STATOR/TRIGGER (ELECTRIC MODELS)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 1 SEAL–Rest (Use where applicable)
2 1 REST (OIL INJECTION) I.D. of rest rope hole is 1/4 IN.
3 1 PLUG–Starter Handle
2 1 REST KIT I.D. of rest rope hole is 1/3 IN.
3 1 PLUG–Starter Handle
4 1 GROMMET–Oil Tank
5 1 PLUG–Primer Hole
6 2 NUT (M6 x 1)
7 2 WASHER
8 2 SPACER
9 4 WING NUT
10 4 WASHER
11 4 WASHER (Neoprene)
12 1 COVER–Flywheel
13 5 SCREW (M5 x 30) 50 5.6
14 1 STATOR
15 1 O RING (S/N-USA-0G589999/BEL-9973099 & BELOW)
16 1 TRIGGER ASSEMBLY
17 1 TRIGGER ASSEMBLY (S/N-USA-0G590000/BEL-9973100 & ABOVE)

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
