Mercury 30 Service Manual

90-826148R2 MARCH 1997 ELECTRICAL - 2A-7
S/N-0G380074/BEL-MAN-9928507/BEL-ELEC-9928480&Below
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 2 NUT (1/4-20) 50 5.6
2 2 LOCKWASHER
3 1 CABLE ASSEMBLY (BLACK–4 IN.)
4 1
SOLENOID ASSEMBLY
5 1 BUSHING ELECTRIC
6 1 GROMMET
7 2 SCREW (M6 x 25) 40 4.5
8 2 NUT (8–32) 20 2.3
9 1 CABLE (RED) ELECTRIC
10 1 BATTERY CABLE (NEGATIVE)
11 1 INSULATOR
12 1 RETAINER
13 1 STATOR (MANUAL)
14 5 SCREW (M5 x 30) 50 5.6
15 1 O RING
16 1 TRIGGER
17 1 HARNESS ASSEMBLY
18 1 PLATE–Electrical
19 3 BUSHING–Flanged
20 3 GROMMET
21 3 WASHER
22 3 SCREW (M6 x 25) 100 11.3
23 1 SCREW (M6 x 14) Drive Tight
24 1 TPM ASSEMBLY
25 3 SCREW (M5 x 20) 80 9.0
26 1 HARNESS ASSEMBLY–Engine (MANUAL)
27 1 HARNESS ASSEMBLY–Engine (ELECTRIC)
28 1 TERMINAL BLOCK
29 2 SCREW (M5 x 12) MANUAL
30 2 SCREW (10–16 x 3/8 IN.)
31 AR STA–STRAP
32 1 VOLTAGE REGULATOR
33 1 J–CLIP ELECTRIC
34 1 CABLE (BLACK–11 IN.)
35 2 SCREW (M6 x 35) 80 9.0
36 1 CABLE (BLACK–9 IN.)
37 1 SCREW (10-16 x 3/5 IN.)
38 2 CDM ASSEMBLY
39 4 SCREW (M6 x 14) 80 9.0
40 2 HI–TENSION CABLE KIT
41 2 BOOT KIT
42 2 SPARK PLUG (NGK# BP8H-N-10) 240 20 27.1
42 2 SPARK PLUG (NGK# BPZ-8H-N-10) 240 20 27.1
43 1 SOCKET ASSEMBLY–FUSE ELECTRIC
44 1 FUSE

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
